Ormesa Juditta

Tilt Manual Wheelchair

  • Seating system prevents pressure sores
  • Designed for easy transfers
  • 3 models available

The Juditta is designed for patients that spend long periods lying down or partially reclined. Transfers are easy with swing-away, height- and angle-adjustable leg support. The Juditta’s headrest, leg rests, arm height, seat angle, seat height, seat length, leg angle, and leg length are all adjustable. The seating system has been designed and pressure-map tested to prevent pressure sores.

Call (08) 9209 1777 or

Ormesa Juditta Features

Ormesa Juditta ergonomic

Ergonomic seating system

The Juditta’s ergonomic design means the seating conforms to the user—relieving and redistributing pressure, meaning longer comfortable sitting sessions. The backrest promotes proper trunk alignment and creates zero pressure on the spine.

Ormesa Juditta pressure

Get the tilt that’s right for you

The Juditta’s superior tilt and recline function mean you can get the ideal support position, preventing pressure sores. Tilt and recline are operated by two independent gas springs that absorb the user’s weight and patient handling easier.

Ormesa Juditta breathable

Hygienic and breathable

The seat and backrest are covered with a patented fire-resistant, breathable and anti-slip material.  The headrest is made of a special anti-bacterial material with closed cells—highly resistant to external chemical agents.

Ormesa Juditta transfers

Easy transfer

The “scissor opening” sides allows the easy and safe transfer of the user, with no obstacles

Ormesa Juditta customise

Customisable

Removable, swingaway, tilt-adjustable legrests; height and flexion-extension adjustable footrests; depth-adjustable seat

Ormesa Juditta 3 tilting models

3 tilting models

B12: tilting, for indoor use, with four 5 inches solid swivelling wheels, brakes on rear wheels

B30: tilting, with 8 inches front solid swivelling wheels and 12 inches rear wheels; drum brakes operated by a single control pedal and pedal to climb steps

B60: tilting, with 8 inches front solid swivelling wheels and 22 inches rear wheels with brake. Anti-tip device and pedal to climb steps

Juditta Specifications



Juditta B12

ormesa juditta
Juditta B12 size 36 size 40 size 45 size 50
A Seat bottom width cm 36 cm 40 cm 45 cm 50
B Seat bottom depth cm 40-43-46-49 cm 40-43-46-49 cm 40-43-46-49 cm 40-43-46-49
C Backrest width cm 47 cm 47 cm 52 cm 57
D Total width cm 60 cm 60 cm 65 cm 70
H Seat bottom inclination-tilt da 10° a 35° da 10° a 35° da 10° a 35° da 10° a 35°
I Backrest inclination da 13° a 38° da 13° a 38° da 13° a 38° da 13° a 38°
Aid weight kg 35 kg 35 kg 36 kg 37
Max capacity kg 100 kg 120 kg 130 kg 140



Juditta B30

ormesa juditta
Juditta B30 size 36 size 40 size 45 size 50
A Seat bottom width cm 36 cm 40 cm 45 cm 50
B Seat bottom depth cm 40-43-46-49 cm 40-43-46-49 cm 40-43-46-49 cm 40-43-46-49
C Backrest width cm 47 cm 47 cm 52 cm 57
D Total width cm 60 cm 60 cm 67 cm 72
H Seat bottom inclination-tilt da 10° a 35° da 10° a 35° da 10° a 35° da 10° a 35°
I Backrest inclination da 13° a 38° da 13° a 38° da 13° a 38° da 13° a 38°
Aid weight kg 35 kg 35 kg 39 kg 40
Max capacity kg 100 kg 120 kg 130 kg 140



Juditta B60

ormesa juditta
Juditta B60 size 36 size 40 size 45 size 50
A Seat bottom width cm 36 cm 40 cm 45 cm 50
B Seat bottom depth cm 40-43-46-49 cm 40-43-46-49 cm 40-43-46-49 cm 40-43-46-49
C Backrest width cm 47 cm 47 cm 52 cm 57
D Total width cm 69 cm 69 cm 74 cm 79
H Seat bottom inclination-tilt da 10° a 35° da 10° a 35° da 10° a 35° da 10° a 35°
I Backrest inclination da 13° a 38° da 13° a 38° da 13° a 38° da 13° a 38°
Aid weight kg 41 kg 41 kg 42 kg 43
Max capacity kg 100 kg 120 kg 130 kg 140

Support Documents

Accessories

ormesa juditta

824-R reclinable tray adjustable in tilt, backwards-forwards, with security block

828 abdominal belt

834 padded abduction block, adjustable in height and backwards-forwards

892 padded footplate covering, removable

896 padded tray, 824 covering, removable

905 set of hand brakes with single lever, for rear wheels, only for B30 and B60

914 footrest lock. Locks the two footrests together to form one unit

916 padded leg panel, alternative to the calf rests

932 anti-tip device only for B30 (as standard on B60)

933 IV pole, only for B30 and B12

936 headrest cover, removable

938 water-proof cover

×
×
