The Meyra XXL and XXL HD don’t back down.
Built to move users up to 200 kg (XXL) or 250 kg (XXL HD), with a great stable and sturdy design, the XXL and XXL HD are tough.
Thanks to the power tilt-in-space and recline function, as well as the choice of powered separate or centre mounted footrests, you can be tough and comfortable.
Simply download the form, complete the required details, and submit it to sales@acmobility.com.au.
Have Questions? Contact us.
Save this product
Share with your friends:
The power seat tilt and power backrest recline features of the XXL and CCL HD offer pressure relief and numerous health benefits such as reducing the risk of pressure injuries and fatigue, making it more comfortable for you to use the wheelchair for a longer duration. The rear-wheel drive configuration of the XXL & XXL HD ensures a smooth ride with larger casters and a high top speed, while being easier to handle at higher speeds. The wheelchair is built with reinforced components for strength and stability, and offers a wide range of standard and power options such as power tilt-in-space and recline function, powered separate or center-mounted footrests. With the XXL & XXL HD’s LED lighting system, you can safely navigate your way even in low light conditions.
You can choose from five different frame and accent colours, allowing you to customise the wheelchair to your liking. The power tilt-in-space and recline function, along with the option of powered separate or center-mounted footrests, ensures that the XXL & XXL HD Bariatric Power Wheelchair is both durable and comfortable. It is a dependable and enduring choice for individuals looking for a power wheelchair.
Seat width 530 – 700
Seat depth 430 – 600
Back rest height 530 – 570
Leg length adjustment 370 – 510
Armrest height adjustment 170 – 280
Front seat height options
(with /without cushion)
420 – 470 / 460 – 560 / 530 – 630
Length with footrests 1,150
Length without footrests 850
Width overall 670
Height without headrest 1,020 – 1,150
Transport length 850
Transport height minimum 650
Front wheel size 260 x 70 (10“ x 2 3/4”)
Rear wheel size 356 x 75 (14“ x 3”)
Max. obstacle height 60
Turning radius 950
Driving range with 70ah batteries 30 – 35
Empty transport weight min. approx. 130 kg
Client weight max XL / XXL 200 kg / 250 kg
Driving speeds 6 kmh /10 kmh
Motor options 2 x 300W / 2 x 350W
Driving range max. 35 km
Permitted gradient 13 %
Electric tilt-in-space 0° to +18°
Mechanical tilt-in-space 0° to +10°
Power backrest recline -10° to +50°
Mechanical backrest recline -10° to +30°
Dimensions in mm, Weights in kg, Speed in km/h, Tolerance ± 10 mm
Heavy Duty: Ideal for those with larger body frames, supporting up to 200 kg (XXL) and 250 kg (XXL HD).
Powerful: Equipped with powerful motors for fast and efficient mobility: 2 x 300W or 2 x 350W motor options.
Power Seat Tilt: Power seat tilt and power backrest recline options available for pressure relief and health benefits.
Rear Wheel Drive: For a smooth ride with larger casters and high top speed.
Reinforced: Built with reinforced components for strength and stability.
Tough, With Lots Of Options: Wide range of standard and power options including power tilt-in-space and recline function, and powered separate or center-mounted footrests.
LED Lighting System: LED lighting system for safe navigation in low light conditions.
Frame and Accent Colours: Customisable with five different frame and accent colours.
